<?xml version="1.0"?>
<interface>
  <!-- interface-requires gladevcp 0.0 -->
  <requires lib="gtk+" version="2.16"/>
  <!-- interface-naming-policy project-wide -->
  <object class="GtkWindow" id="window1">
    <child>
      <object class="GtkFrame" id="frame1">
        <property name="visible">True</property>
        <property name="label_xalign">0</property>
        <property name="shadow_type">none</property>
        <child>
          <object class="GtkAlignment" id="alignment1">
            <property name="visible">True</property>
            <property name="left_padding">12</property>
            <child>
              <object class="GtkTable" id="table1">
                <property name="visible">True</property>
                <property name="n_rows">7</property>
                <property name="n_columns">2</property>
                <child>
                  <object class="HAL_LED" id="spindle-orient-led">
                    <property name="visible">True</property>
                    <property name="led_shape">2</property>
                  </object>
                  <packing>
                    <property name="left_attach">1</property>
                    <property name="right_attach">2</property>
                  </packing>
                </child>
                <child>
                  <object class="GtkLabel" id="label2">
                    <property name="visible">True</property>
                    <property name="label" translatable="yes">motion.spindle-orient:</property>
                  </object>
                </child>
                <child>
                  <object class="GtkLabel" id="label4">
                    <property name="visible">True</property>
                    <property name="label" translatable="yes">motion.spindle-locked</property>
                  </object>
                  <packing>
                    <property name="top_attach">2</property>
                    <property name="bottom_attach">3</property>
                  </packing>
                </child>
                <child>
                  <object class="HAL_LED" id="spindle-is-oriented-led">
                    <property name="visible">True</property>
                    <property name="led_shape">2</property>
                  </object>
                  <packing>
                    <property name="left_attach">1</property>
                    <property name="right_attach">2</property>
                    <property name="top_attach">1</property>
                    <property name="bottom_attach">2</property>
                  </packing>
                </child>
                <child>
                  <object class="HAL_Button" id="spindle-is-oriented">
                    <property name="label" translatable="yes">motion.spindle-is-oriented:</property>
                    <property name="visible">True</property>
                    <property name="can_focus">True</property>
                    <property name="receives_default">True</property>
                  </object>
                  <packing>
                    <property name="top_attach">1</property>
                    <property name="bottom_attach">2</property>
                    <property name="x_options"></property>
                    <property name="y_options"></property>
                    <property name="x_padding">4</property>
                    <property name="y_padding">4</property>
                  </packing>
                </child>
                <child>
                  <object class="HAL_LED" id="spindle-locked-led">
                    <property name="visible">True</property>
                    <property name="led_shape">2</property>
                  </object>
                  <packing>
                    <property name="left_attach">1</property>
                    <property name="right_attach">2</property>
                    <property name="top_attach">2</property>
                    <property name="bottom_attach">3</property>
                  </packing>
                </child>
                <child>
                  <object class="HAL_Label" id="spindle-orient-angle">
                    <property name="visible">True</property>
                    <property name="text_template">motion.spindle-orient-angle: %f</property>
                    <property name="label_pin_type">1</property>
                  </object>
                  <packing>
                    <property name="right_attach">2</property>
                    <property name="top_attach">3</property>
                    <property name="bottom_attach">4</property>
                  </packing>
                </child>
                <child>
                  <object class="HAL_LED" id="spindle-brake-led">
                    <property name="visible">True</property>
                    <property name="led_shape">2</property>
                  </object>
                  <packing>
                    <property name="left_attach">1</property>
                    <property name="right_attach">2</property>
                    <property name="top_attach">5</property>
                    <property name="bottom_attach">6</property>
                  </packing>
                </child>
                <child>
                  <object class="GtkLabel" id="label5">
                    <property name="visible">True</property>
                    <property name="label" translatable="yes">motion.spindle-brake:</property>
                  </object>
                  <packing>
                    <property name="top_attach">5</property>
                    <property name="bottom_attach">6</property>
                  </packing>
                </child>
                <child>
                  <object class="HAL_SpinButton" id="spindle-orient-fault">
                    <property name="visible">True</property>
                    <property name="can_focus">True</property>
                    <property name="invisible_char">&#x25CF;</property>
                    <property name="adjustment">fault-adj</property>
                  </object>
                  <packing>
                    <property name="left_attach">1</property>
                    <property name="right_attach">2</property>
                    <property name="top_attach">6</property>
                    <property name="bottom_attach">7</property>
                  </packing>
                </child>
                <child>
                  <object class="GtkLabel" id="label6">
                    <property name="visible">True</property>
                    <property name="label" translatable="yes">motion.spindle-orient-fault:</property>
                  </object>
                  <packing>
                    <property name="top_attach">6</property>
                    <property name="bottom_attach">7</property>
                  </packing>
                </child>
                <child>
                  <placeholder/>
                </child>
                <child>
                  <placeholder/>
                </child>
              </object>
            </child>
          </object>
        </child>
        <child type="label">
          <object class="GtkLabel" id="label1">
            <property name="visible">True</property>
            <property name="label" translatable="yes">&lt;b&gt;M19-related pins&lt;/b&gt;</property>
            <property name="use_markup">True</property>
          </object>
        </child>
      </object>
    </child>
  </object>
  <object class="GtkAdjustment" id="fault-adj">
    <property name="lower">-100</property>
    <property name="upper">100</property>
    <property name="step_increment">1</property>
    <property name="page_increment">10</property>
    <property name="page_size">10</property>
  </object>
  <object class="GtkAdjustment" id="level-adj">
    <property name="upper">100</property>
    <property name="step_increment">1</property>
    <property name="page_increment">10</property>
    <property name="page_size">10</property>
  </object>
</interface>
