The I/O Termination board (pn 7535P and 7535N) provides optically isolated digital I/O. Each board has 16 input terminals and 8 output terminals. The board connects directly to the I/O ribbon cable connectors on MOTENC PCI boards as well as DSPMC/IP Ethernet controllers. All I/Os are optically isolated and are clearly marked for quick and easy installation.

* LEDs for every I/O
* 2 Amps output current capacity
* 7535P - PNP I/O (Sourcing)
* 7535N - NPN I/O (Sinking)
* Optically Isolated Digital I/O

INPUTS:
16 Inputs, grouped as banks of 4 inputs each, with a total of 4 banks.
Input voltage range of 12 to 30 Volts DC..

OUTPUTS:
8 Outputs, grouped as two banks of 4 outputs each. Output Current Capacity of 2 Amps per output, 10 to 30VDC.

Connection Diagrams:
7535P-v3 PNP Wiring Diagram
7535N NPN Wiring Diagram

Part Number	Description
p/n 7535P-v3 $229.00, Buy Now	PNP Sourcing I/O. Inputs: 16, Outputs: 8, Opto-Isolated, 12v-30v DC
p/n 7535N $229.00, Buy Now	NPN Sinking I/O. Inputs: 16, Outputs: 8, Opto-Isolated, 12v-30v DC

---



Connection Diagram: 7521 wiring Details

Part Number	Description
ENCTERM p/n 7521 Price List, Buy Now	Analog Inputs: 8 Analog Output: 8 Differential Encoder Counters: 8

---

DAC/ADC/Encoder Termination Board for MOTENC-Lite (pn7525)

The 7525 Breakout board provides terminations for Encoders, DAC, and ADC for MOTENC-Lite PCI board. The board has 4 Differential Encoder Inputs (A, B, and Index), 8 DAC Analog Outputs and 8 ADC Analog Inputs. The board connects directly to the ENC/DAC/ADC ribbon cable connectors on the MOTENC-Lite PCI board. All signals are clearly marked for quick and easy installation. A jumper setting allows power for the Encoders to be drawn from the PC or from an external source. When using PC power, the encoders are supplied 5V DC @ 1A for all four encoders.

Connection Diagram: 7525 wiring Details

Part Number	Description
DAC/ADC/ENC Termination Board p/n 7525 Price List, Buy Now	Analog Inputs: 8 Analog Output: 8 Differential Encoder Counter Inputs: 4

---
